MetaDiag 2007
- electronic diagnostic system used by service technicians to
obtain information regarding possible faults and quickly identify
defects.
New CLAAS Diagnostic Interface is a high performance 4
CAN-interface communicating by WiFi that allows a transfer of
CAN-data between desktop PC or notebook and CAN-bus.
It is highly mobile and flexible tool that can handle single CAN
messages as well as comprehensive CAN traffic in a complex network.
With the help of some optional features the can be used for error
monitoring and diagnostics.
The interface has an integrated logic that can detect error frames
and count them into an internal memory. This is done for finding
sporadic errors like falsified messages. There is also a
measurement of analoge current levels implemented.
CLAAS Diagnostic System:Lexion, Tucano, Avero, Jaguar, Xerion, Axion, Axos, Talos,
Nexos/Elios, Quadrant, Rollant, Variant, Cougar, Disco, Liner,
Cargos, Quantum.
MetaDiag:Ares, Arion, Atles, Axion, Axos, Celtis, Ceres, Cergos,
Dionis, Ergos, Ergos 4x6, Fructus, Gamme T, Nectis, Pales, RB,
Temis, 1X0-94
CANUSB (old interface) is a high performance CAN-interface for the
USB slot that allows a transfer of CAN-data between desktop PC or
notebook and CAN-bus. It is highly mobile and flexible tool that
can handle single CAN messages as well as comprehensive CAN traffic
in a complex network. With the help of some optional features the
CANUSB can be used for error monitoring and diagnostics. The
interface has an integrated logic that can detect error frames and
count them into an internal memory. This is done for finding
sporadic errors like falsified messages. There is also a
measurement of analoge current levels implemented.
Supported models:
1X0-94, Ares, Arion, Atles, Axion, Axos, Celtis, Ceres, Cergos,
Dionis, Ergos, Ergos 4x6, Fructus, Gamme T, Nectis, Pales, RB,
Temis.
CDS (CLAAS Diagnostic System) - allow defects to be identified
quickly and the on-board management system to be configured and
updated.
Supported models:Lexion, Tucano, Avero, Dominator, Mega, Medion, Jaguar, Xerion,
Axion, Atos, Axos, Talos, Nexos/Elios, Ares, Celtis, Ergos, Cergos,
Ceres, Quadrant, Rollant, Variant, Cougar, Disco, Liner, Cargos,
Quantum, Scorpion, Torion.
