2024 New Arrival - LAUNCH X431 PAD V ELITE
1. High configuration hardware: 10.1 inch Touchscreen, sun readable
screen, protection grade IP65, more waterproof, more resistant to
falling, and the vehicle can work normally after rolling
|
2. Support 5G Wi-Fi Diagnosis , 4GB RAM + 128GB ROM (can up to
256GB)
|
3.Updated the connector from Smart Box 3.0 to Smart Lick C , added
Super Remote Diagnostic
|
4. Online ECU Programming + Online Coding + J2354 Programming
|
5. OE-Level Full System Diagnosis + 50 More Reset Service
|
6. Full Bi-Directional Control / Active Test + ECU Coding + Guide
Function
|
7. FCA AutoAuth Access + SCN Online Coding
|
8. Support support Topological Graph + J2534/RP1210/D-PDU / CAN FD
DolP New Protocols
|
9. 25 Language Support , No language barrier
|
10. Auto VIN Scan + Remote Diagnostic +Diagnostic Feedback
+Maintenance records, ect
|
11. Support the expansion of 24V truck diagnosis (Optional)
|
12. Added Tesla _EV vehicles: Model - 3, Model - S and Model- X (
Buy in MALL)
|
13. 2 Years Free Update
besides, you can use all functions as normal after 2 years free
update,it will not be locked
|
14. 5 Years Warranty + Free Tech Supports
|
15. Extended module: Compatible with Oscillograph, X-PROG 3, TSGUN
Wand, RF-Sensor, BST360 Battery Test, VSP600 Videoscope, ADAS, 24V
Heavy Duty software , Wi-Fi printer, New energy vehicle,
Multimeter, Ignition analysis etc.
|
and more ..
Multi-Language Supports
Support English, French, Spanish, German, Russian, Korean,
Japanese, Portuguese, Italian, Polish, Dutch, Hungarian, Finnish,
Simplified, Czech, Turkish, Greek, Arabic, Danish, Persian,
Romanian, Serbian, Swedish, Chinese Traditional
Language is free, switch at will
Compared with the programming products supported in the market,
LAUNCH X431 PAD V supports more models and more comprehensive
functions
a. Support 30+ Car Brands, overing European cars, American cars,
Asian cars and Chinese cars ,and keep increating
b. function including: Online Coding, Online Programming,Online
Parametric Configuration,On-Line Matching And Calibration, Fuel
Quality Defect Firmware Upgrade and more
c. Applicable vehicle models for online programming : For Mercedes
Benz, for Porsche, for FAW Volkswagen, for Kia, for bmw, for
Nissan, for SKODA, for Mazda ,for VW, for Beijing Hyundai, For
Seat, for Fiat, for Audi, For SAIC Rongwei, for Renault, for China
GM, For SAIC MG, for GAC MOTOR, for Ford, for Shanghai Volkswagen ,
for Hyundai, keep increasing...
Vehicle Programming Benefits
1.For Great Wall : support Great Wall, Haval (ECM/AT #), WEY, Oula
2.for Volkswagen Audi advantages: online programming (support for
programming and resurrection), firmware upgrade for fuel quality
defects, online parametric configuration, part number upgrade,
support for manual programming ( more online codes, more online
parametric configurations, more online matching and calibration)
3. for Benz advantages : manual control unit programming; clone.
4. for BMW advantages: the code setting data is up to March 22, and
it supports modification. Brush hiding has function help, and brush
hiding has expert mode.
5. for Mercedes Benz advantages : 13 years ago, it had
initialization startup (programming, code setting, anti-theft,
initialization). After 13 models, the engine module and
transmission module can be cloned.
6. for Ford advantages: Since 2018, all models and functions of
FORD original factory have been online.
Basic function: After 18 years, X-431 is offline
Special function: After 18 years, X-431 will be online
The original manufacturers of Chrysler and FIAT have gradually put
all models and functions online since 2018. X-431 all functions
online
What situation needs to perform programming ?
1. Programming new ECUs: Replace new ECU(Determine if programming
or coding is required based on fault code prompts). It can read and
back up the original ECU data of the vehicle. (Note: The newly
purchased spare part numbers need to be equal to the original
ones.)
2. Reprogramming second-hand ECUs: Clear second-hand ECU data for
reprogramming(if the second-hand has the anti-theft data, it needs
to be used with LAUNCH X-PROG3 to clear anti-theft data first, and
then match it with the original anti-theft data before
reprogramming.).
3.Update the ECU: Some of the ECU has BUGs so it will cause some
faults that are difficult to repair. ( For BMW 2889 DME intake
valve, carbon deposition, and some of F serious machine oil lamps
can't be zero.)
4. Fixing lost data of ECU: When the software in the ECU corrupts
the program due to battery or grounding issues(the Hardware is
normal), re-programming can rectify it back to normal operation.
5. Reprogramming on failed programming ECU: If the programming
fails but the hardware didn't damage, the LAUNCH X431 PAD V can
reprogram the module in Manual Mode which is compatible with
VW/Audi/Ben/BMW. And it supports Programming Backup/Restoration
that is applied to match anti-theft data for Mercedes-Benz engine
modules and transmission modules, which requires purchasing X-431
PROG3 additionally (If the programming fails, ECU will not
communicate and you will not be able to access the system ).
Please Note: Programming is no IP Limited except Spain and
Portugal.
Work with the PC installed with the OEM diagnostic software to
perform the J2534 reprogramming
Support Protocols:
CAN/CAN_PS/FT_CAN_PS/SW_CAN_PS/FT_ISO15765_PS/ISO15765/IS
O15765_PS/SW_ISO15765_PS/ISO14230/ISO14230_PS/ISO9141/ISO9
141_PS/J1850PWM/J1850PWM_PS/J1850VPW/J1850VPW_PS
Support for Toyota, Lexus, Thain, Honda, Acura, Volvo, Volkswagen,
Audi, Sieter, Skoda, Bentley, Lamborghini, BMW, GM, Opel, Saab,
Chevrolet, Cadillac, Ford, Chrysler, Subaru, Mercedes, Land Rover,
Jaguar, ect ,Updating
Support DolP, CAN FD and other protocols with SmartLink C connector
it is compatible with CAN-FD protocol and supports the latest For
GM vehicles manufactured after 2020. Adopts advanced CRC algorithms
to accommodate more data from 8 to 64 bytes in the CAN frame, which
runs faster than other products and reduces the risk of undetected
errors to greatly enhance the user experience.
Supports For Chevrolet Onix 2020-2021 year
Supports For Chevrolet Tracker 2020 year
Supports For Chevrolet Suburban 2021 year
Supports For Chevrolet Tahoe 2021 year
Supports For Buick
Supports For Cadillac Escalade 2021 year
Supports For Cadillac Escalade 2021 year
Supports For GMC Yukon 2021 year
Supports For GMC Yukon XL 2021 year
Supports For Holden
Supports For DAEWOO
Supports For Alpheon
Supports For Ravon
Supports For Pontiac
Supports For Saturn
Supports For Hummer
DoIP
With Diagnostics over DoIP, diagnostics introduced over UDS are
used over TCP/IP and Ethernet. This enables much higher data rates
than with CAN. save both in terms of time and expenses in the case
of complex diagnostic tasks and flash applications. Compatible with
BMW (F&G chassis), Volvo models (2018 later), Land Rover &
Jaguar models (2017 later).
What is Programming Function ? What different is Online Programming
and Offline/J2534 Programming ?
Programming Function is to finish program/ rewrite/ code/ match new
ECU after new module replacement. Taking your business to a new
height, it can for :
1) program the new adaptive data to the on-board modules;
2) replace the existing software/firmware in the ECUs;
3) match the component control modules after repair or replacement;
4) flash the hidden functions and
5) enhance the vehicle performance.
Online Programming is download the original data from automaker
service directly , it is ensures the correctness and latest version
of the data you get , Improves the success rate of programming !!!
Offline/J2534 Programming is for you had the data , just write it
to you ecu directly( if you do not have the data , you can not do
programming function ).
LAUNCH X431 PAD V supports Online Programming + Offline/J2534
programming , it is more powerful and Cost-effective than other
J2534 tool :
* X-431 PAD V online programming does not require an expensive
online account, just connect to WIFI, saving maintenance costs.
* smartbox adopts dual WIFI communication to improve programming
speed, thereby reducing the possibility of programming errors
* When using J2534 tool, in addition to the connector, it is also
necessary to consider issues such as adapting the computer,
installation costs, and complete functions, which is not
cost-effective.
AutoAuth for FCA SGW
you will have access to the security gateway module on 2017 and
newer Fiat/ Chrysler/ Dodge/ Jeep vehicles(2017-2022), so that the
diagnostic tool can clear codes, run bi-directional active tests,
actuations, relearns or even IMMO key programming (pulls PIN &
write), ADAS calibration assistance etc.
North American Registration/Login
Address:https://webapp.autoauth.com/
Europe Registration/Login
Address:https://www.technicalinformation.fiat.com
(please note: FCA account needs to be purchased )
OE-Level Full System Diagnosis and support Topological Graph
1. Support full-make, full-system, full-function rapid diagnosis,
read DTC, clear DTC, read data stream, actuation test, etc.
2. LAUNCH X431 PAD V auto scan tool new-added topology module
mapping,it is easy to view the communication structure between
modules.you can directly access all system to perform
functions,view live data in graph. Better to let you know the car
clearly and simple !
Bi-Directional Control ( Active Test )
The launch scanner x431 pad v support: Injector Buzz Test , Idle
Speed Adjustment, Window Lock Test, Door Lock Test, Glow On/Off,
ACG On/Off, Pump and Valve Test, Fuel Pump, EGR Test, IMRC Test,
EVAP Test, A/C Compressor Activation, Turn on the Radiator Fan,
Clutch On and Off, Acceleration Device Test, Modulate the Throttle,
Solenoid Valve, tank Ventilation, Switch Cylinder Correction
Off/On, etc.
ECU Coding: Alter the Car on Your Demand
From manufacturer-specific reprogramming to full diagnostic
capability, this LAUNCH diagnostic scanner also has the magic power
“ECU Coding” to keep you on the cutting edge:
1) You can match, relearn, and code the newly installed ECU module
after making repairs or replacements. 2) You can change the
market-specific settings to activate higher-level car functions and
disable unneeded features, breaking limitations.
50+ HOT Services. Handle Your Daily Car Maintenance.
1. Oil Reset Service
reset the oil service for the engine oil life system, which
calculates an optimal oil life change interval depending on the
vehicle driving conditions and weather events.It needs to be
performed in the following cases:
1. If the service lamp is on, run car diagnostics first for
troubleshooting. After that, reset the driving mileage or driving
time, so as to turn off the service lamp and enable a new driving
cycle.
2. If the service lamp is not on, but you have changed the engine
oil or electric appliances that monitor oil life, you need to reset
the service lamp.
2. Electronic Parking Brake Rese
reset the brake pad after replacing the brake pad.It needs to be
performed in the following cases:
1. The brake pad and brake pad wear sensor are replaced.
2. The brake pad indicator lamp is on.
3. The brake pad sensor circuit i
3 Steering Angle Calibration
reset the steering angle, after replacing the steering angle
position sensor, replacing steering mechanical parts (such as
steering gearbox, steering column, end tie rod, steering knuckle),
performing four-wheel alignment, or recovering car body
4. ABS Bleeding
perform various bi-directional tests to check the operating
conditions of Anti-lock Braking System (ABS). It needs to be
performed in the following cases:
1. When the ABS contains air.
2. When the ABS computer, ABS pump, brake master cylinder, brake
cylinder, brake line, or brake fluid is replaced.
5. Tire Pressure Monitor System Reset
quickly look up the tire sensor IDs from the vehicle’s ECU, reset
tire pressure and turn off the tire pressure MIL. It needs to be
performed in the following cases: Tire pressure is too low, tire
leaks, tire pressure monitoring device is replaced or installed,
tire is replaced, tire pressure sensor is damaged, and tire is
replaced for the car with tire pressure monitoring function.
6 .Gear Learning
perform tooth learning for the car, to turn off the MIL. It needs
to be performed in the following cases:
1. After the engine ECU, crankshaft position sensor, or crankshaft
flywheel is replaced.
2. The DTC 'tooth not learned' is present.
7. Injector Coding
write injector actual code or rewrite code in the ECU to the
injector code of the corresponding cylinder, so as to more
accurately control or correct cylinder injection quantity. It needs
to be performed in the following cases: After the ECU or injector
is replaced.
8 . Battery Maintenance System Reset
perform a resetting operation on the monitoring unit of vehicle
battery, in which the original low battery fault information will
be cleared and battery matching will be done. It needs to be
performed in the following cases:
1. The main battery is replaced.
2. The battery monitoring sensor is replaced.
9. Diesel Particulate Filter (DPF) Regeneration
clear PM (Particulate Matter) from the DPF filter through
continuous combustion oxidation mode (such as high temperature
heating combustion, fuel additive or catalyst reduce PM ignition
combustion) to stabilize the filter performance. It needs to be
performed in the following cases:
1. The exhaust back pressure sensor is replaced.
2. The PM trap is removed or replaced.
3. The fuel additive nozzle is removed or replaced.
4. The catalytic oxidizer is removed or replaced.
5. The DPF regeneration MIL is on and maintenance is performed.
6. The DPF regeneration control module is replaced.
10. Electronic Throttle Position Reset
make initial settings to throttle actuators and returns the learned
values stored on ECU to the default state. Doing so can accurately
control the actions of regulating throttle (or idle engine) to
adjust the amount of air intake.
11 EGR Adaption
learn the EGR (Exhaust Gas Recirculation) valve after it is cleaned
or replaced.
12 .Gearbox Matching
This function can complete the self-learning of the gearbox and
improve the shift quality. It needs to be performed in the
following cases: When the gearbox is disassembled or repaired.
13 .AdBlue Reset (Diesel Engine Exhaust Gas Filter)
After the diesel exhaust treatment fluid (car urea) is replaced or
filled up, urea
reset operation is required.
14 .Transport Mode
To lower vehicle power consumption, user may perform the following
operations: limit vehicle speed, not wake up the network for door
open and disable remote key etc. In this case, deactivating
transport mode is needed to recover vehicle being normal.
15. Windows Calibration
perform door window matching to recover the ECU initial memory, and
recover the automatic ascending and descending function of power
window.
and More ...
LAUNCH X-431PAD V main hardware features
1. 10.1 inch Gorilla Glass Screen:Better scratch performance；Good
Outdoor Readable performace
2. CPU:8 core Cortex-A53 2.0GHz；Cache:4GB；Hard disk:64GB.Running
faster；dual WIFI stable signal.
3. IP65 Devices’ Protection: Waterproof and dustproof; Reliable
quality
4. 180°adjustable kickstand,easy to use the device
Work for Both 12V cars and 24V trucks (Optional)
If you need heavy duty truck software, please contact with us and
buy software from us.
then we will help you authorize heavy duty truck software and send
the Non-16pin connector kit to you and you can use this disgnostic
tool to diagnose 12v cars and 24v trucks without HD module.
LAUNCH X431 PAD V Function Help Features
Quickly solve your problem, save time
1. Remote diagnose: Support online real-time communication and
remote diagnostic service through text, picture, and file between
device and device, and between device and remote desktop, with low
network bandwidth and system resources occupancy.
2. Diagnostic feedback: For model software and function errors met
during the use, please submit the feedback immediately. LAUNCH will
response as soon as possible.
3. diagnostic report: View comprehensive diagnostic report, remote
diagnostic report, and data stream playback.
4.Abundant maintenance data are available, which helps repair
professionals diagnose and repair vehicles efficiently, accurately
and profitabl
supprt data flow waveform display ,DTC Lookup ,ect
Work with X431 X-PROG3 to do anti-theft matching, anti-theft
programming (Optional)
★Fast and accurate reading and writing of data.
★ Powerful functions, supporting Mercedes-Benz infrared key
reading/writing, BMW engine ISN code reading, engine reading in
BENCH mode, etc.
Functions
★Read BMW engine ISN code.
★Read/write BMW CAS4+ and FEM chips.
★Read/write Audi fifth-generation steering column
chipsH3.Read/write Audi fifth-generation steering column chips.
★Read/write EEPROM.
★Read/write MCU.
★VW Fourth-generation Dump Mode All Keys Lost.
★Read engine in BENCH mode.
★ Read gearbox data.
★More features are constantly updated………
Guided Functions for VW and for Audi Brands
X431 PAD V has guided functions among all online products of
LAUNCH.
Guided Functions show all specific operating instructions step by
step, and automatically run the instructions to do the resetting,
matching, coding etc.
You just need to follow the instructions and click
complete/continue to do it.
It is a good assistant helping you to find a way during the car
repairing.
NEW OPTIONAL FUNCTIONS (option functions)
1. X431 ADAS Mobile/PRO:When the adaptive cruise control module
(ACCM), radar sensor or front bumper has been replaced or does not
meet the maintenance calibration requirements, you need to perform
"radar calibration" on your vehicle.
2. VSP600-Videoscop: helps technicians to check issues on
unreachable area in a vehicle. With 6 levels light strength,
technicians can easily adjust the brightness according to the
environment.
3. TSGUN: a professional tire pressure diagnostic tool that
integrates TPMS sensor activation, reading, learning and
pro-gramming. It activates reading tire pressure information by
receiving signals at low or high frequencies. Check for abnormal
conditions in time to prevent tire pressure problems.
4. X-PROG3 Immobilizer: turn this X431 diagnostic scanner into a
capable IMMO service tool, providing fast, easy, and intuitive k-ey
pro-gramming for VAG group vehicles with 2/3/3.5 gen. IMMO, and
most Asian cars with low-level antitheft systems; also to have
completed IMMO & K-ey Pro-gramming (read & write 1200+ EEPROM and
MCU chips, etc.) for VW/Audi/Skoda/Seat models manufactured after
2008 with 4/5/5.5/6 gen. IMMO system.
5. X431 PRINTER: Print out diagnostic data/ reports
O2-1 ScopeBox, Oscilloscope: to quickly acquire the circuit signal,
and slowly display the waveform for better data analysis.
6. BTS360 Bluetooth Battery Tester: to get a thorough test of the
vehicle battery.
7. ADAS . ect
