As the newest released Autel scanner, Autel MaxiPro MP808Z-TS makes
Autel MP808BT & MP808TS pale by comparison in hardware & software
configurations. What's more, Autel MaxiPro MP808Z-TS has been added
new functions that can not achieved with Autel MP808TS & MaxiCOM
MP808BT. All new functions are ready for use out of box and no
software update is required: ECU Coding, battery testing, special
functions, TPMS ToolKit function and FCA Auto Auth. No matter in
what aspects, Autel MP808Z-TS is far ahead of MP808TS & MP808BT.
Promotion Notice:Autel MaxiPRO MP808Z-TS provides 2 years free update,needs
Registration time from May 31th to Dec 31th,2023Main Configuration Updates Based on Autel MP808/MP808BT/MP808TS:1. Operating system move on to Android 11 from Android 4.4.
2. Upgraded 8-core ROCKCHIP RK3566 Processor replacing old ROCKCHIP
RK3188 Processor.
3. 4GB/64GB Expanded Storage.
4. Dual Frequency 2.4/5.0GHZ Wi-Fi.
5. Optimazed newest Software version. No need to upgrade to get new
added functions such as bi-directional control, battery testing,
special functions and FCA Auto Auth.
Conclusion: Thanks to these upgrade, Autel MP808Z-TS fix running latency
problem, low response, network unstable problem and other problems
that frequently happened in the old MP808/MP808BT/MP808TS. Autel
MP808Z-TS not only offers more intuitive naviagtion interface, but
aslo enhanced the running & response speed by 3 times.
Functionality Highlights of Autel Scanner MaxiPro MP808Z-TS:1. Autel MP808Z-TS features the same ECU coding functions as Autel
MaxiSys MS906BT and support other high-end functions such as
Activate hidden functions, customize OE-settings, VAG guided
functions and so on.
2. Autel MP808Z-TS ranks first in Autel TPMS product line in terms
of TPMS function, features the completely the same TPMS functions
as Autel MaxiTPMS TS608. The new added ToolKit functions enables
program TPMS by OEM Part No, unlock ECU for Toyata, unlock
REDI7002A, awake OEM sensors, check key fob and more, which is not
available on all the other scan tools such as
MK808TS/MP808TS/MS906TS/MS906 Pro-TS/MK906 Pro-TS.
3. Support Australia Holden and Ford
Autel Scanner MaxiPro MP808Z-TS: Same ECU Coding Functions As
MaxiSys MS906BT/MaxiCOM MK906BTWith much less budget spent, Autel MaxiPRO MP808Z-TS can perform
ECU coding function which normally only available on models that
above MK906BT/MS906BT/MS906TS, and support much more vehicle models
than MP808 & MP808BT.
Online ECU Coding:Perform Online software modifications to a vehicle to allow the use
of functions not available in the car when it left the factory for
different reasons, mainly local regulations. Online coding for BMW,
for VW, for Nissan, for Nissan-GTR, for Infiniti, for Hyundai, for
Toyota, for Ford, for Mazda, etc.;
Offline ECU Coding/Adaptation:Write the codes from the original modules to newly replaced
modules, work for Jaguar, for Vauxhall, for Opel, etc.
Activate Hidden Functions:Autel MP808Z-TS support hidden function activation and current
function ban: such as automatic engine Start-Stop function,
automaztic mirror folding/unfolding, Seatbelt warning sounds;
Closing the windows after locking the car door with the key and
much more.
Customize OE-Settings:Take dahsboard display as examples: Displaying of the real speed
via GPS signal; Displaying the amount of fuel consumption at a
given speed; Incoming call display; Select whether the display
should be on the dashboard or head-up display and much more. Other
setting are also supported such as lighting settings, acoustic
warning signal settings and much more.
Replacement Module Matching:Autel Scanner MaxiPRO MP808Z-TS support matching/ coding/ recoding/
adaptation after new modules or component being replaced to allow
it be recognized by the car system or modify relevant parameters
for the best drivability.
Note: All the above mentioned functions vary by car makes, models and
year. Please consult us to check compatibility before purchasing.
Rank First In Autel TPMS Product Line: Same TPMS Functions As TS608
> MS906 Pro-TS/MS906TS> MP808TS>MK808TSAs the newly launched Autel Scanner with comprehesnive diagnostic
funbction, Autel MP808Z-TS inherited all the TPMS function from
Autel TS608, making it the most powerful TPMS tool in Autel TPMS
product line:
New Added TPMS ToolKit Functions:1. Program TPMS by OEM Part No;
2. Unlock TPMS ECU for Toyata;
3. Unlock REDI7002A;
4. Awake OEM Sensors;
5. Check Key Fob Signal
With Autel MaxiPRO MP808Z-TS, it is easy to perform all the
following functions:1. Program TPMS by OEM Part No: TPMS by OEM Part No.: Easy way to activate and program MX-Sensors
with the original sensor’s OEM part number, able to program up to
20 sensors at the same time.
2. Activate All Known TPMS Sensors: Trigger almost all known TPMS sensors (315/433MHz), including the
OE sensors, Autel MX-sensors, and other sensors in the market.;
Sleep/Park Mode: For those OEM sensors that are delivered in Sleep
Mode, this function is used to wake and set them to Park Mode.
3. TPMS Check & Diagnostics: check the status of the TPMS system, retrieve sensor IDs and DTCs
present in the ECU, detect TPMS DTCs with detailed description,
TPMS Sensor live data such as sensor ID, tire pressure, tire
temperature, sensor battery, sensor position, and
sensor frequency, perform special functions for resetting or
re-matching, and then clear the DTCs and turn off the faulty light
4. Programming Autel MX-Sensor: Programs new MX-Sensor to replace OEM sensors by 4 methods
Copy by Activation – Program the sensor ID retrieved from activated
sensor
Copy by OBD – Program the sensor ID retrieved from TPMS ECU
Copy by Input – Manually input the original sensor ID for
programming
Auto Create – Create a random ID to program MX-Sensor
5. TPMS Sensors Relearn: This function is used to write the newly programmed sensor IDs
into the vehicle ECU for sensor recognition. Four relearn methods:
OBD Relearn; Stationary Relearn; Automatic Relearn; Copy Relearn
6. TPMS Retrofit: For cars that don't have TPMS module, this function can install
TPMS System to backup and save the data of the original vehicles
for safety driving.
Autel MaxiCOM MP808Z-TS: OE-Level All System In-depth Diagnostics !As the fully ugrade version of Autel MP808TS & MaxiPRO MP808BT,
Autel MP808Z-TS can access all available systems or modules such as
Engine, Transmission, ABS, SRS, IC, BCM, TPMS, Air Conditioning,
IMMO, Air Suspension, Airbags, Cruise Control, etc. to perform more
in-depth diagnose with feaster speed: retrieve ECU info, get freeze
frame data, live data in graphic & text, read codes, clear codes,
active test and so on for accurate efficient solution.
Intuitive & Convenient Auto Scan:Autel MP808Z-TS features one-click Auto scan to allow users quickly
know the health status of all systems to take proper fix avoid any
potential risk in the future. In addition, Autel MaxiPRO MP808Z-TS
support 4 methods for Vehicle Identification:
Auto VIN
Manual VIN Input;
Automatic Selection;
Manual Selection.
Bi-Directional Control Scan Tool Autel MP808Z-TS:Same Level As
MaxiSys MS906BT/MS906TS/MS906 Pro !Autel scanner MaxiCOM MP808Z-TS features the same Bi-Directional
Control functions as more expensive models such as MS906BT, MK906BT
& MS906 Pro, able to output the commands signals to ECUs & and
receives information from vehicle control modules, which can help
technicians to determine the functioning status of the tested parts
without dismantling and decide if it need to be replaced.
For example:
in the case of OBD II generic information Mode 1 (which relates to
data parameters), use Autel MK808Z-BT to initiates a request for
information from the powertrain control module (PCM), and the PCM
responds by sending the information back to the scan tool for
display. If it's not responding, you will know that there is
problem with PCM. It can also be used to actuate relays, injectors
and coils, perform system tests, etc.
Here below are the most commonly tested parts:
Headlamp Adjustment; Window Wipers Setting; Window Glass Up & Down;
Sunroof Switch on/off; Sunroof Switch on/off; Power Seats
Adjustment; steering wheel heating, horns, ABS, Fuel pump & etc.
Note: Autel MP808Z-TS support bi-directional controls on various modules
but it's not universally compatible for all vehicles. Available
tests vary depending on the make, year, and model. Please provide
VIN for us to check compatibility.
No IP Restriction & Language Switching Service:Autel MP808Z-TS is designed to service global users with different
language background and this is reason why it offer various
language options. The default language of this device is English.
It can now support up to 15 languages: English, Spanish, French,
German, Russian, Italian, Portuguese, Japanese, Korean, Chinese,
Swedish, Dutch, Polish and etc.
Note: If you need to switch to a different language, please provide
device S/N (12 digits, at the back of the device, eg: VB7GL6C0579)
Autel Scanner MaxiPRO MP808Z-TS: 31+ One-stop Maintenance & Reset
Services (still expanding)Autel Scanner MaxiPRO MP808Z-TS is able offers over 31 services
function includes commonly used reset & maintenance functions that
a DIYer or auto technician would need for everyday car care. Here
below is some of the most popular services:
Oil Reset: Reset the new calculation of Engine Oil Life System for
an accurate reading of the next oil change.
EPB Reset: Reset the calipers, brake discs or pads after the
electronic parking brake system is repaired.
BMS Reset: Reset after replacing the battery to clear the low
battery fault information of the original battery and protect the
new battery.
IMMO / Key Programming: Disable a lost vehicle key to protect the
vehicle from being stolen and add the new key. (work only on Asian
cars that feature low-grade IMMO systemI
Injector Coding: Code a new injector to better identify injectors
to accurately control fuel injection.
ABS Bleeding: Perform to bleed the brake system to restore ABS
braking sensitivity and obtain a firm brake pedal.
SAS Adjustment: Clear the fault steering angle sensor memories,
perform reset steering angle sensor, and turn off steering wheel
warning light.
Throttle Relearn: Reset the throttle actuators to accurately
regulate throttle (or idle engine) operations, helps keep your
idling and acceleration smooth.
Headlight Matching: initialize the adaptive headlight system
...
More Can be Done After Maintenance / Reset or Component
Replacement: initial adaptation, Auto-learning, relearn, auto
detection. For example:Crankshaft Sensor Learn and etc.
Note: The above mentioned is just a small portion of all supported
services and more are not listed. Please also know that Not All
service & Special functions are universally compatible. Please send
VIN number and the functions you need to us to check compatibility.
